Central Instrumentation Lab

Central Instrumentation Laboratory (CIL)

IIMT University - Empowering Research and Innovation

Usage Policy & Guidelines

All researchers and students must adhere to the CIL's operational and safety procedures. Prior booking is mandatory for all instruments.

View Complete Policy →

Instrument Booking Form

Submit your request for instrument usage, including sample details and required time slots.

Go to Booking Form →

Lab Coordinator

Dr. Neha Saxena

Assistant Professor

Email: [email protected]

Instrumentation Details

Image of Trinocular Microscope

Trinocular Microscope

Make: Olympus | Model: 1.3 Megapixels | Year: 2021

Key Specifications:

  • Trinocular Microscope with camera.
  • Eye pieces: 10X, 15X, 20X.
  • Objective lenses: 5X, 10X, 40X, 100X (Oil immersion lens).
Image of Digital UV Vis Spectrophotometer

Digital UV Vis Spectrophotometer

Make: Edu DAP | Model: 118 | Year: 2021

Key Specifications:

  • Single Beam Digital Wavelength with 0.1 nm increments.
  • Range: 200 – 1000 nm.
  • Bandwidth: 2 nm.
  • Manual 4 position sample changer.
Image of Double beam UV Vis Spectrophotometer

Double beam UV Vis Spectrophotometer

Make: LABMAN | Model: LMSP-UV1900 | Year: 2024

Key Specifications:

  • Double Beam System.
  • Wavelength Range: 190-1100 nm.
  • Spectral Bandwidth: 1.0 nm.
  • Scanning Speed: Up to 4000 nm/min (Fast scanning).
Image of Autoclave

Autoclave

Make: Thymol | Model: TAI-903 Vertical Triple Walled | Year: 2021

Key Specifications:

  • Material: SS-304 (all chambers & rings).
  • Working Pressure: 15–22 psi (1.0–1.5 kg/cm²).
  • Safety Testing: Hydrotested to ≈55 psi.
Image of BOD Incubator

BOD Incubator / Cooling Incubator (CI-10 plus)

Make: EduDAP | Model: CI-10 plus | Year: 2021 (for small unit)

Key Specifications:

  • Temp. range: 0-60 °C.
  • Adjustable 3 number of trays.
  • CLS (Custom Logical Safe) control system with logical safety devices.
Image of Refrigerated Centrifuge

Refrigerated Centrifuge

Make: REMI | Model: C-24 Plus

Key Specifications:

  • Max. Speed: 20000 RPM.
  • Max. RCF: 37570g.
  • Max. Capacity: 400ml.
  • Lowest Temp: – 8°C.
Image of PCR Thermal Cycler

PCR Thermal Cycler

Make: EduDAP | Model: LA-949

Key Specifications:

  • Sample capacity: 96X0.2 ml.
  • Temp. range: 0-100°C.
  • Heating rate: 5 (°C/sec) | Cooling rate: 4 (°C/sec).
Image of High-Performance Liquid Chromatography

High-Performance Liquid Chromatography (HPLC)

Make: Lasany | Model: LI-6200 | Year: 2024

Key Specifications:

  • Pump Type: Dual-piston reciprocating pump.
  • Flow Rate Range: 0.01 to 10.00 mL/min.
  • Pressure Limit: Up to 6000 psi.
  • Compatible with chromatographic data analysis software.
Image of ELISA Micro Plate Reader

ELISA Micro Plate Reader

Make: Beneshphera | Model: RT-600

Key Specifications:

  • Wavelength Range: 400–750 nm.
  • Microplate Compatibility: 96-well plates.
  • Reading Speed: <5 seconds per 96 wells.
Image of Gel Electrophoresis (Vertical & Horizontal)

Gel Electrophoresis (Vertical & Horizontal)

Make: Biotek Brew | Model: Vertical Gel Electrophoresis System | Year: 2024

Key Specifications:

  • Gel size (max): 70x50 mm.
  • Buffer required: 200 ml.
  • Electrodes Platinum.
Image of Ultrasonic Probe Sonicator

Ultrasonic Probe Sonicator

Make: Labman | Model: PRO650

Key Specifications:

  • Frequency: 20-25KHz (Automatic tracking).
  • Output Power: 6.5-650W (adjustable).
  • Process capacity: 0.5-500ml.
Image of Rotary Microtome (ERBA Type)

Rotary Microtome (ERBA Type)

Make: EduDAP | Model: RMT-20

Key Specifications:

  • Feed adjustment: 1 - 25 micron.
  • Minimum Thickness: 1 micron.
  • Total Feed Excursions: 28 micron.
Image of Universal Combined Kjeldhal Digestion and Distillation Unit

Universal Combined Kjeldhal Digestion and Distillation Unit

Make: EduDAP | Year: 2021

Key Features:

  • Electrically heated MS tubular stand with two shelves and glass fume duct.
  • Separate energy regulators for distillation and digestion.
